CBS-1232 Plus Series Twin Coffee Brewer (1 Gal)
The twin station CBS-1232 Plus Series Twin Station Coffee Brewer is a perfect hot beverage solution for low- to medium-volume self-service environments such as convenience stores, cafeterias, specialty coffee shops, or office coffee service (OCS). Designed specifically for smaller batch brewing, these high-quality brewers possess many of the legendary features and reliable performance you’ve come to expect from Extractor® branded products at a competitive price.
Standard Features:
Plastic Brew Basket
Brew Basket Sensor
Manual Hot Water Faucet
ECO Mode
USB Plug-in Feature
Electrical Lattice
Laser Welded Tank
Push Button Interface
The twin station CBS-1232 Plus Series Twin Station Coffee Brewer is a perfect hot beverage solution for low- to medium-volume self-service environments such as convenience stores, cafeterias, specialty coffee shops, or office coffee service (OCS). Designed specifically for smaller batch brewing, these high-quality brewers possess many of the legendary features and reliable performance you’ve come to expect from Extractor® branded products at a competitive price.
Standard Features:
Plastic Brew Basket
Brew Basket Sensor
Manual Hot Water Faucet
ECO Mode
USB Plug-in Feature
Electrical Lattice
Laser Welded Tank
Push Button Interface
The twin station CBS-1232 Plus Series Twin Station Coffee Brewer is a perfect hot beverage solution for low- to medium-volume self-service environments such as convenience stores, cafeterias, specialty coffee shops, or office coffee service (OCS). Designed specifically for smaller batch brewing, these high-quality brewers possess many of the legendary features and reliable performance you’ve come to expect from Extractor® branded products at a competitive price.
Standard Features:
Plastic Brew Basket
Brew Basket Sensor
Manual Hot Water Faucet
ECO Mode
USB Plug-in Feature
Electrical Lattice
Laser Welded Tank
Push Button Interface
Specifications
Measurements
Height: 26.25 in / 66.7 cm
Width: 19.75 in / 50.2 cm
Depth: 20.5 in / 52 cm
Shipping Weight: 55 lbs / 25 kg
Capacity
Tank Capacity: 5.48 G / 20.74 L
8 oz / 236 ml cup/hr: 254
12 oz / 355 ml cup/hr: 169
16 oz / 473 ml cup/hr: 127
20 oz / 591 ml cup/hr: 101
Standard Electrical Configurations
Electrical Connection: Terminal Block
Volts: 208-240
Amps: 17.1-25.5
Phase: Single
*Please see international spec sheet for additional configurations
Water Specifications
Water Inlet Size: 3/8" (Male Flare)
Minimum Flow Rate: 1.5 gpm
Water Pressure Requirement: 20-75 psig
